Marathon R399A industrial IEC motor delivers 3 HP at 3500 RPM in a TEFC (totally enclosed fan-cooled) enclosure. Dual-voltage design supports 230/460V 3-phase operation, making it suitable for various industrial and commercial HVAC applications including compressors, pumps, and fan drives. Built to IEC standards for global compatibility.
Marathon R399A IEC Motor 3 HP 3-Phase 3500 RPM
Regal Rexnord - Marathon
$1,069.95
In Stock
- SKU:
- R399A
Specifications
- Product Type:
- Industrial Motor
- Subcategory:
- IEC Motor
- Application:
- Commercial/Industrial
- System Type:
- Compressor, Pump, Fan Drive
- Installation Type:
- OEM Replacement
- Voltage:
- 230/460V
- Voltage Class:
- Line Voltage
- Phase:
- Three Phase
- Horsepower:
- 3 HP
- RPM:
- 3500 RPM
- Speeds:
- 1
- Mounting Type:
- Rigid Base
- Frame Size:
- 90L Frame
- Motor Type:
- Three Phase
- Power (kW):
- 2.2 kW
- Service Factor:
- 1.15
- KVA Code:
- K
- NEMA Design:
- B
- Power Factor:
- 87.5%
- Duty:
- Continuous
- Ambient Temperature:
- 40°C
- Starting Method:
- Line Or Inverter
- Inverter Duty:
- Constant 20:1
- Bearings:
- Ball / Ball
- Bearing Sizes:
- shaft end 6205, opposite end 6205
- Shaft Type:
- IEC
- Overall Length:
- 12.83"
- Frame Length:
- 7.08"
- Mounting Orientation:
- Horizontal
- IP Rating:
- IP45
- Material:
- Aluminum
- Certifications:
- UL Recognized, CSA, CE
- Country of Origin:
- China
- UPC:
- 722856027412
- Lifecycle Status:
- Active
