Marathon 20 HP close-coupled pump motor rated for 230/460V three-phase operation at 1768 RPM. TEFC enclosure provides protection in wet or dusty environments. Designed for direct-drive pump applications in industrial and commercial systems.
Marathon GT3125A Close Coupled Pump Motor 20 HP 3-Phase
Regal Rexnord - Marathon
$2,100.95
- SKU:
- GT3125A
Specifications
- Product Type:
- Close-Coupled Pump Motor
- Subcategory:
- Industrial Pump Motor
- Application:
- Commercial/Industrial
- System Type:
- Pump System
- Installation Type:
- OEM Replacement
- Voltage:
- 230/460V
- Voltage Class:
- Line Voltage
- Phase:
- Three Phase
- Horsepower:
- 20 HP
- RPM:
- 1768 RPM
- Speeds:
- 1
- Mounting Type:
- Close Coupled
- Fuel Type:
- Electric
- Frame Size:
- 256JM Frame
- Motor Type:
- Three Phase
- Power (kW):
- 14.9 kW
- Service Factor:
- 1.15
- KVA Code:
- G
- NEMA Design:
- B
- Power Factor:
- 83.5%
- Duty:
- Continuous
- Ambient Temperature:
- 40°C
- Starting Method:
- Line Or Inverter
- Inverter Duty:
- Constant 10:1/Variable 10:1
- Bearings:
- Ball / Ball
- Bearing Sizes:
- shaft end 6309, opposite end 6209
- Shaft Type:
- JM
- Overall Length:
- 27.89"
- Frame Length:
- 11.73"
- Mounting Orientation:
- Horizontal
- Assembly Position:
- F1/F2 Capable
- IP Rating:
- IP55
- Hazardous Location:
- Division 2 T2B
- Material:
- Cast Iron
- Certifications:
- UL Listed, CSA, CE
- Country of Origin:
- Mexico
- UPC:
- 722856063199
