Marathon 7.5 HP three-phase general-purpose industrial motor with TEFC enclosure and 1800 RPM. Features NEMA 213T frame, reversible rotation, keyed shaft (1 3/8" diameter x 3 3/8" length), and Class F insulation with 1.15 service factor. Suitable for demanding industrial applications requiring reliable, enclosed fan-cooled operation.
Specifications
- Product Type:
- General Purpose Motor
- Subcategory:
- Three-Phase Industrial
- Application:
- Industrial
- Installation Type:
- OEM Replacement
- Voltage:
- 230/460V
- Voltage Class:
- Line Voltage
- Phase:
- Three Phase
- Amperage:
- 19.0/9.5 A
- Horsepower:
- 7.5 HP
- RPM:
- 1768 RPM
- Speeds:
- 1
- Frame Size:
- 213T Frame
- Mounting Type:
- Rigid Base Mount
- Fuel Type:
- Electric
- Power (kW):
- 5.6 kW
- Service Factor:
- 1.15
- KVA Code:
- H
- NEMA Design:
- B
- Power Factor:
- 79.3%
- Duty:
- Continuous
- Ambient Temperature:
- 40°C
- Starting Method:
- Line Or Inverter
- Inverter Duty:
- Constant 10:1/Variable 10:1
- Bearings:
- Ball / Ball
- Bearing Sizes:
- shaft end 6307, opposite end 6206
- Mounting Orientation:
- Horizontal
- Assembly Position:
- F1/F2 Capable
- IP Rating:
- IP43
- Hazardous Location:
- Division 2 T2B
- Material:
- Rolled Steel
- Certifications:
- UL Listed, CSA, CE
- Country of Origin:
- Mexico
- UPC:
- 722856182210
