Marathon G142 1 HP three-phase AC induction motor rated 208-230/460V, 1725 RPM. ODP (Open Drip-Proof) enclosure suitable for fan and blower applications. NEMA 56 frame. Designed for industrial and commercial HVAC systems requiring reliable motor performance.
Marathon G142 AC Induction Motor 1 HP 3-Phase 1725 RPM
Regal Rexnord - Marathon
$488.95
In Stock — 10+ available
- SKU:
- G142
Specifications
- Product Type:
- AC Induction Motor
- Subcategory:
- Three-Phase Industrial Motor
- Application:
- Commercial/Industrial
- System Type:
- Fan and Blower Systems
- Installation Type:
- OEM Replacement
- Voltage:
- 208-230/460V
- Voltage Class:
- Line Voltage
- Phase:
- Three Phase
- Horsepower:
- 1 HP
- RPM:
- 1725 RPM
- Speeds:
- 1
- Frame Size:
- 56 Frame
- Mounting Type:
- Rigid Base (Footed)
- Fuel Type:
- Electric
- Motor Type:
- Three Phase
- Power (kW):
- 0.75 kW
- Service Factor:
- 1.15
- KVA Code:
- L
- NEMA Design:
- B
- Power Factor:
- 68.5%
- Duty:
- Continuous
- Ambient Temperature:
- 40°C
- Starting Method:
- Across The Line
- Bearings:
- Ball / Ball
- Bearing Sizes:
- shaft end 6203, opposite end 6203
- Shaft Type:
- Single
- Overall Length:
- 11.35"
- Frame Length:
- 7 1/16"
- Mounting Orientation:
- Horizontal
- Assembly Position:
- F1 Only
- IP Rating:
- IP22
- Material:
- Rolled Steel
- Certifications:
- UL Recognized, CSA, CE
- Country of Origin:
- Mexico
- UPC:
- 722856040749
- Lifecycle Status:
- Active
