Marathon F1203 Auger Drive Motor 3/4 HP 115/208-230V 1725 RPM 48NZ Frame TEFC

Specifications

Product Type:

Auger Drive Motor

Subcategory:

Farm Duty Motor

Application:

Agricultural

Voltage:

115/208-230V

Phase:

Single Phase

Amperage:

10.8/5.3-5.4 A

Horsepower:

0.75 HP

RPM:

1725 RPM

Speeds:

1

Frame Size:

48NZ Frame

Mounting Type:

Round

Material:

Rolled Steel

Motor Type:

Capacitor Start

Power (kW):

0.56 kW

Service Factor:

1.0

KVA Code:

K

NEMA Design:

L

Power Factor:

64%

Duty:

Continuous

Ambient Temperature:

40°C

Starting Method:

Across The Line

Bearings:

Ball / Ball

Bearing Sizes:

shaft end 6203, opposite end 6203

Shaft Type:

Special Extension Both Sides

Overall Length:

11 5/16"

Frame Length:

7"

Mounting Orientation:

Horizontal

Assembly Position:

F1 Only

IP Rating:

IP43

Certifications:

UL Recognized, CSA

Country of Origin:

Mexico

UPC:

722856027948

Lifecycle Status:

Discontinued by manufacturer
