LEESON Condenser Fan Motor, 0.50 HP, 1 Ph, 60 Hz, 208-230 V, 1200 RPM, 48Z Frame, OAO - X221

Specifications

Voltage:

208-230V

Horsepower:

0.5 HP

RPM:

1075 RPM

Mounting Type:

Round - Extended Studs

Phase:

Single Phase

Frame Size:

48Z Frame

Speeds:

1

Motor Type:

PSC

Power (kW):

0.37 kW

Service Factor:

1.0

KVA Code:

C

Power Factor:

91.6%

Duty:

Continuous

Ambient Temperature:

60°C

Starting Method:

Across The Line

Bearings:

Ball / Ball

Bearing Sizes:

shaft end 6203, opposite end 6203

Shaft Type:

Single Special Extension

Overall Length:

11 15/16"

Frame Length:

4 1/2"

Mounting Orientation:

Shaft Up

IP Rating:

IP10

Material:

Rolled Steel

Certifications:

UL Recognized, CSA

UPC:

722856037640

Lifecycle Status:

Discontinued by manufacturer

Product Type:

Condenser Fan Motor
