Leeson 2 HP three-phase industrial motor, 3450 RPM, NEMA 56HC frame, TEFC enclosure. Rated 230/460V 60Hz with 5.0/2.5A. Constructed entirely from 300-series stainless steel for superior corrosion resistance in washdown and severe environments. Keyed shaft 5/8" diameter. Reversible rotation. 1-year manufacturer warranty.
Specifications
- Product Type:
- Three-Phase Industrial Motor
- Subcategory:
- General Purpose Motor
- Application:
- Industrial
- Installation Type:
- OEM Replacement
- Voltage:
- 230/460V
- Voltage Class:
- Line Voltage
- Phase:
- Three Phase
- Amperage:
- 5.0/2.5 A
- Horsepower:
- 2 HP
- RPM:
- 3450 RPM
- Speeds:
- 1
- Frame Size:
- 56HC Frame
- Mounting Type:
- C-Face Mount
- Fuel Type:
- Electric
- Material:
- 300 Series Stainless Steel
- Motor Type:
- Three Phase
- Power (kW):
- 1.5 kW
- Service Factor:
- 1.15
- KVA Code:
- M
- NEMA Design:
- B
- Power Factor:
- 87.5%
- Duty:
- Continuous
- Ambient Temperature:
- 40°C
- Starting Method:
- Line Or Inverter
- Inverter Duty:
- Constant 20:1
- Bearings:
- Ball / Ball
- Bearing Sizes:
- shaft end 6205, opposite end 6205
- Shaft Type:
- Nema 56
- Overall Length:
- 13.77"
- Mounting Orientation:
- Horizontal
- Assembly Position:
- F1/F2 Capable
- IP Rating:
- IP55
- Certifications:
- UL Recognized, CSA, CE
- Country of Origin:
- China
- UPC:
- 691720104040
- Lifecycle Status:
- Active
