Leeson 1.5 HP single-phase motor rated 115/230V, 60 Hz, 1800 RPM with TEFC enclosure and rigid base mount. Features 56C NEMA frame, 5/8" keyed shaft, Class F insulation, and double-sealed bearings. Stainless steel construction resists corrosion in washdown and damp environments. Service factor 1.15; reversible rotation.
Specifications
- Product Type:
- AC Motor
- Subcategory:
- Single-Phase General Purpose
- Application:
- Residential/Commercial
- Installation Type:
- OEM Replacement
- Voltage:
- 115/230V
- Voltage Class:
- Line Voltage
- Phase:
- Single Phase
- Amperage:
- 15.8A @ 115V, 7.9A @ 230V
- Horsepower:
- 1.5 HP
- RPM:
- 1725 RPM
- Speeds:
- 1
- Frame Size:
- 56C Frame
- Mounting Type:
- Rigid Base Mount
- Fuel Type:
- Electric
- Material:
- Stainless Steel
- Motor Type:
- Capacitor Start / Capacitor Run
- Power (kW):
- 1.1 kW
- Service Factor:
- 1.15
- KVA Code:
- K
- NEMA Design:
- N
- Power Factor:
- 75%
- Duty:
- Continuous
- Ambient Temperature:
- 40°C
- Starting Method:
- Across The Line
- Bearings:
- Ball / Ball
- Bearing Sizes:
- shaft end 6205, opposite end 6203
- Shaft Type:
- Nema 56
- Overall Length:
- 13.3"
- Frame Length:
- 7.54"
- Mounting Orientation:
- Horizontal
- Assembly Position:
- F1 Only
- IP Rating:
- IP55
- Country of Origin:
- China
- UPC:
- 691720399507
- Lifecycle Status:
- Active
