Leeson 7.5 HP single-phase crop dryer motor with 182TZ NEMA frame and Totally Enclosed Air Over (TEAO) enclosure. Operates at 3450 RPM on 230V, 60 Hz with 85.5% efficiency and Class F insulation. Capacitor start/run design with rigid base mounting, ideal for agricultural and farm duty applications.
Specifications
- Product Type:
- Single-Phase Motor
- Subcategory:
- Farm Duty / Crop Dryer Motor
- Application:
- Residential/Commercial
- System Type:
- Agricultural Equipment, Crop Dryer
- Installation Type:
- OEM Replacement
- Voltage:
- 230V
- Voltage Class:
- Line Voltage
- Phase:
- Single Phase
- Amperage:
- 30 A
- Horsepower:
- 7.5 HP
- RPM:
- 3450 RPM
- Speeds:
- 1
- Frame Size:
- 182TZ Frame
- Mounting Type:
- Rigid Base
- Fuel Type:
- Electric
- Material:
- Rolled Steel
- Motor Type:
- Capacitor Start / Capacitor Run
- Power (kW):
- 5.6 kW
- Service Factor:
- 1.0
- KVA Code:
- F
- Power Factor:
- 98%
- Duty:
- Continuous
- Ambient Temperature:
- 40°C
- Starting Method:
- Across The Line
- Bearings:
- Ball / Ball
- Bearing Sizes:
- shaft end 6206, opposite end 6205
- Shaft Type:
- Single Special Extension
- Overall Length:
- 17 7/16"
- Frame Length:
- 12 1/2"
- Mounting Orientation:
- Horizontal
- IP Rating:
- IP43
- UPC:
- 691720103760
