Leeson 122191.00 3 HP 3-Phase Motor 3490 RPM 230/460V

Leeson

$1,120.95
Write a Review
SKU:
122191.00

Currently out of stock

Tell us where it’s going and we’ll come back with a price and freight cost.

Request price & availability

We reply within one business day — quotes@globalpartsupply.com

Specifications

Product Type:
Three-Phase Electric Motor
Subcategory:
Industrial/Commercial
Application:
Commercial/Industrial
Installation Type:
OEM Replacement
Voltage:
230/460V
Voltage Class:
Line Voltage
Phase:
Three Phase
Horsepower:
3 HP
RPM:
3490 RPM
Speeds:
1
Fuel Type:
Electric
Mounting Type:
Rigid Base
Frame Size:
145JM Frame
Power (kW):
2.2 kW
Service Factor:
1.15
KVA Code:
N
NEMA Design:
B
Power Factor:
86%
Duty:
Continuous
Ambient Temperature:
40°C
Starting Method:
Across The Line
Bearings:
Ball / Ball
Bearing Sizes:
shaft end 6206, opposite end 6203
Shaft Type:
JM
Overall Length:
16.43"
Frame Length:
8"
Mounting Orientation:
Horizontal
Assembly Position:
F1 Only
IP Rating:
IP55
Material:
Rolled Steel
Certifications:
UL Recognized, CSA, CE
Country of Origin:
USA
UPC:
691720052075
Lifecycle Status:
Active
Leeson 3 HP three-phase electric motor rated for 3490 RPM operation. TEFC (totally enclosed fan-cooled) enclosure suitable for industrial and commercial HVAC applications. Dual voltage 230/460V design allows flexible installation in various electrical configurations.
