Leeson 119488.00 Motor 1.5 HP 3-Phase 1750 RPM

Leeson

$902.95

In Stock

Write a Review
SKU:
119488.00
Adding to cart… The item has been added

30-day returns on most unused, uninstalled parts Secure checkout with cards, PayPal or Google Pay Questions? quotes@globalpartsupply.com

Shipping: $43.75 per item. The same price to anywhere in the 50 states.

Buying several? Shipping is charged per item — request a combined quote.

Ships same or next business day · UPS Ground or comparable carrier, typically 1–5 business days.

Specifications

Product Type:
Three-Phase Electric Motor
Subcategory:
Industrial Duty Motor
Application:
Commercial/Industrial
System Type:
Compressor, Fan, Pump
Installation Type:
OEM Replacement
Voltage:
230/460V
Voltage Class:
Line Voltage
Phase:
Three Phase
Horsepower:
1.5 HP
RPM:
1750 RPM
Speeds:
1
Fuel Type:
Electric
Mounting Type:
Round
Frame Size:
56C Frame
Power (kW):
1.1 kW
Service Factor:
1.15
KVA Code:
L
NEMA Design:
B
Power Factor:
67.7%
Duty:
Continuous
Ambient Temperature:
40°C
Starting Method:
Across The Line
Bearings:
Ball / Ball
Bearing Sizes:
shaft end 6205, opposite end 6203
Shaft Type:
Nema 56
Overall Length:
13.16"
Frame Length:
7 1/2"
Mounting Orientation:
Horizontal
Assembly Position:
F1 Only
IP Rating:
IP55
Material:
Stainless Steel
Certifications:
UL Recognized, CSA
Country of Origin:
USA
UPC:
691720052457
Lifecycle Status:
Active
Leeson 1.5 HP three-phase electric motor rated for 230/460V dual-voltage operation. TEFC (totally enclosed fan-cooled) enclosure provides protection in demanding environments. Runs at 1750 RPM and is suitable for industrial HVAC applications including compressors, fans, and pumps.
