Leeson 116468.00 Brake Motor 0.75 HP 3-Phase 1725 RPM

Leeson

$1,282.95

In Stock

Write a Review
SKU:
116468.00
Adding to cart… The item has been added

30-day returns on most unused, uninstalled parts Secure checkout with cards, PayPal or Google Pay Questions? quotes@globalpartsupply.com

Shipping: $42.10 per item. The same price to anywhere in the 50 states.

Buying several? Shipping is charged per item — request a combined quote.

Ships same or next business day · UPS Ground or comparable carrier, typically 1–5 business days.

Specifications

Product Type:
Brake Motor
Subcategory:
Three-Phase Industrial
Application:
Industrial
Installation Type:
OEM Replacement
Voltage:
230/460V
Voltage Class:
Line Voltage
Phase:
Three Phase
Horsepower:
0.75 HP
RPM:
1725 RPM
Speeds:
1
Mounting Type:
Rigid Base
Frame Size:
56C Frame
Power (kW):
0.56 kW
Service Factor:
1.15
KVA Code:
L
NEMA Design:
B
Power Factor:
70%
Duty:
Continuous
Ambient Temperature:
40°C
Starting Method:
Across The Line
Bearings:
Ball / Ball
Bearing Sizes:
shaft end 6205, opposite end 6203
Shaft Type:
Nema 56
Overall Length:
15"
Frame Length:
6"
Mounting Orientation:
Horizontal
Assembly Position:
F1 Only
IP Rating:
IP55
Material:
Rolled Steel
Certifications:
UL Recognized, CSA, CE
Country of Origin:
USA
UPC:
691720811009
Lifecycle Status:
Active
Leeson 0.75 HP three-phase brake motor with TENV enclosure, rated for 230/460V operation at 1725 RPM. Designed for industrial applications requiring integrated electromagnetic braking. Suitable for machinery, conveyors, and equipment requiring controlled stopping.
