Leeson 1/3 HP three-phase electric motor rated for 1725 RPM with TENV (totally enclosed non-ventilated) enclosure. Operates on 208-230/460V three-phase power. Suitable for HVAC blower applications, compressors, and other industrial equipment requiring reliable three-phase motor performance.
Specifications
- Product Type:
- Three-Phase Electric Motor
- Subcategory:
- Industrial Duty Motor
- Application:
- Commercial/Industrial
- System Type:
- Compressor, Blower, Pump
- Installation Type:
- OEM Replacement
- Voltage:
- 208-230/460V
- Voltage Class:
- Line Voltage
- Phase:
- Three Phase
- Horsepower:
- 1/3 HP
- RPM:
- 1725 RPM
- Speeds:
- 1
- Fuel Type:
- Electric
- Mounting Type:
- Rigid Base
- Frame Size:
- 56C Frame
- Motor Type:
- Three Phase
- Power (kW):
- 0.25 kW
- Service Factor:
- 1.0
- KVA Code:
- K
- NEMA Design:
- B
- Power Factor:
- 71%
- Duty:
- Continuous
- Ambient Temperature:
- 40°C
- Starting Method:
- Across The Line
- Bearings:
- Ball / Ball
- Bearing Sizes:
- shaft end 6203, opposite end 6203
- Shaft Type:
- Nema 56
- Overall Length:
- 11.97"
- Frame Length:
- 6 5/16"
- Mounting Orientation:
- Horizontal
- Assembly Position:
- F1 Only
- IP Rating:
- IP54
- Hazardous Location:
- Div 1 Exp Proof Cl I Gr Cd Cl Ii Gr Fg T3C
- Material:
- Rolled Steel
- Certifications:
- UL Listed, CSA
- Country of Origin:
- Mexico
- UPC:
- 691720014134
- Lifecycle Status:
- Active
