Leeson 113281.00 Pressure Washer Motor

Specifications

Voltage:

115/230V

Phase:

Single Phase

Horsepower:

2 HP

RPM:

1725 RPM

Speeds:

1

Frame Size:

56HC Frame

Mounting Type:

Rigid Base

Motor Type:

Capacitor Start / Capacitor Run

Power (kW):

1.5 kW

Service Factor:

1.15

KVA Code:

J

NEMA Design:

L

Power Factor:

95%

Duty:

Continuous

Ambient Temperature:

40°C

Starting Method:

Across The Line

Bearings:

Ball / Ball

Bearing Sizes:

shaft end 6203, opposite end 6203

Shaft Type:

Nema 56

Overall Length:

12 7/8"

Frame Length:

8"

Mounting Orientation:

Horizontal

Assembly Position:

F1 Only

IP Rating:

IP22

Material:

Rolled Steel

Certifications:

CSA

Country of Origin:

USA

UPC:

691720011904
