Leeson 112615.00 Auger Drive Motor 1 HP 1725 RPM 115/230V

Leeson

$536.95

In Stock

Write a Review
SKU:
112615.00
Adding to cart… The item has been added

30-day returns on most unused, uninstalled parts Secure checkout with cards, PayPal or Google Pay Questions? quotes@globalpartsupply.com

Shipping: $38.80 per item. The same price to anywhere in the 50 states.

Buying several? Shipping is charged per item — email quotes@globalpartsupply.com for a combined quote.

Ships same or next business day · UPS Ground or comparable carrier, typically 1–5 business days.

Specifications

Product Type:
Auger Drive Motor
Application:
Residential/Commercial
System Type:
Auger Drive System
Installation Type:
OEM Replacement
Voltage:
115/230V
Voltage Class:
Line Voltage
Phase:
Single Phase
Amperage:
14/7 A
Horsepower:
1 HP
RPM:
1725 RPM
Speeds:
1
Frame Size:
56 Frame
Mounting Type:
Flange Mount
Fuel Type:
Electric
Material:
Rolled Steel
Motor Type:
Capacitor Start
Power (kW):
0.75 kW
Service Factor:
1.0
KVA Code:
K
NEMA Design:
N
Power Factor:
63%
Duty:
Continuous
Ambient Temperature:
40°C
Starting Method:
Across The Line
Bearings:
Ball / Ball
Bearing Sizes:
shaft end 6203, opposite end 6203
Shaft Type:
Nema 56
Overall Length:
11.27"
Frame Length:
6 1/2"
Mounting Orientation:
Horizontal
Assembly Position:
F1 Only
IP Rating:
IP54
Country of Origin:
USA
UPC:
691720011010
Lifecycle Status:
Active
1 HP capacitor-start auger drive motor rated for 1725 RPM at 115/230V single-phase 60 Hz. TEFC enclosure with manual overload protection, designed for direct-drive poultry and swine feeding systems. Features ball bearings, Class F insulation, and fully gasketed construction to resist feed dust.
