Leeson 0.5 HP three-phase electric motor rated for 230/460V operation at 1725 RPM. TEFC (totally enclosed fan-cooled) enclosure provides protection in demanding HVAC and industrial applications. Suitable for compressors, pumps, and fan drives requiring reliable three-phase power.
Specifications
- Product Type:
- Three-Phase Electric Motor
- Subcategory:
- Industrial Duty
- Application:
- Commercial/Industrial
- System Type:
- Compressor, Pump, Fan Drive
- Installation Type:
- OEM Replacement
- Voltage:
- 230/460V
- Voltage Class:
- Line Voltage
- Phase:
- Three Phase
- Horsepower:
- 0.5 HP
- RPM:
- 1725 RPM
- Speeds:
- 1
- Fuel Type:
- Electric
- Mounting Type:
- Rigid Base
- Frame Size:
- 56 Frame
- Power (kW):
- 0.37 kW
- Service Factor:
- 1.15
- KVA Code:
- K
- NEMA Design:
- B
- Power Factor:
- 63%
- Duty:
- Continuous
- Ambient Temperature:
- 40°C
- Starting Method:
- Across The Line
- Bearings:
- Ball / Ball
- Bearing Sizes:
- shaft end 6205, opposite end 6203
- Shaft Type:
- Nema 56
- Overall Length:
- 10 1/2"
- Frame Length:
- 5"
- Mounting Orientation:
- Horizontal
- Assembly Position:
- F1 Only
- IP Rating:
- IP55
- Material:
- Rolled Steel
- Certifications:
- UL Recognized, CSA, CE
- Country of Origin:
- USA
- UPC:
- 691720010723
- Lifecycle Status:
- Active
