Leeson 1.5 HP single-phase general-purpose motor rated 1725 RPM, 115/230V. TEFC enclosure with capacitor start/run design, sealed ball bearings, and rigid mounting. Suitable for pumps, compressors, fans, conveyors, and industrial equipment in wet or dusty environments.
Specifications
- Product Type:
- General Purpose Motor
- Application:
- Industrial
- Installation Type:
- OEM Replacement
- Voltage:
- 115/230V
- Voltage Class:
- Line Voltage
- Phase:
- Single Phase
- Amperage:
- 17.2/8.6 A
- Horsepower:
- 1.5 HP
- RPM:
- 1725 RPM
- Speeds:
- 1
- Frame Size:
- 56H Frame
- Mounting Type:
- Rigid
- Fuel Type:
- Electric
- Material:
- Rolled Steel
- Motor Type:
- Capacitor Start / Capacitor Run
- Power (kW):
- 1.1 kW
- Service Factor:
- 1.0
- KVA Code:
- J
- NEMA Design:
- L
- Power Factor:
- 73%
- Duty:
- Continuous
- Ambient Temperature:
- 40°C
- Starting Method:
- Across The Line
- Bearings:
- Ball / Ball
- Bearing Sizes:
- shaft end 6203, opposite end 6203
- Shaft Type:
- Nema 56
- Overall Length:
- 12.99"
- Frame Length:
- 7 1/2"
- Mounting Orientation:
- Horizontal
- Assembly Position:
- F1 Only
- IP Rating:
- IP43
- Certifications:
- UL Recognized, CSA
- Country of Origin:
- USA
- UPC:
- 691720007396
- Lifecycle Status:
- Active
