Leeson 1/3 HP permanent magnet DC motor rated for 1800 RPM at 24V DC input. Features NEMA 56C frame, TENV enclosure, sealed ball bearings, and supports reversible operation via two-lead connection. Ideal for battery or solar-powered applications requiring high starting torque and dynamic braking.
Leeson 108050.00 PMDC Motor 1/3 HP 1800 RPM 24V
Leeson
$591.95
In Stock
Write a Review
Write a Review
Leeson
Leeson 108050.00 PMDC Motor 1/3 HP 1800 RPM 24V
- SKU:
- 108050.00
Specifications
- Product Type:
- Permanent Magnet DC Motor
- Subcategory:
- Fractional Horsepower DC Motor
- Application:
- Residential/Commercial
- Installation Type:
- OEM Replacement
- Voltage:
- 24V DC
- Voltage Class:
- Low Voltage
- Amperage:
- 13.5A
- Horsepower:
- 1/3 HP
- RPM:
- 1800 RPM
- Speeds:
- 1
- Frame Size:
- 56C Frame
- Mounting Type:
- Removable Bolt-On Base
- Motor Type:
- PMDC
- Power (kW):
- 0.25 kW
- Service Factor:
- 1.0
- Output Torque:
- 11.7 lb-in
- Duty:
- Continuous
- Ambient Temperature:
- 40°C
- Bearing Sizes:
- shaft end 6203, opposite end 6203
- Overall Length:
- 10.77"
- Frame Length:
- 4.47"
- Max RPM:
- 1800 RPM
- Fuel Type:
- Electric
- Material:
- Rolled Steel
- Certifications:
- UL Recognized, CSA
- Country of Origin:
- USA
- UPC:
- 691720006733
