Leeson logo - product photo not available

Leeson 107007.00 Gearmotor

Leeson

$919.95

In Stock

Write a Review
SKU:
107007.00
Adding to cart… The item has been added

30-day returns on most unused, uninstalled parts Secure checkout with cards, PayPal or Google Pay Questions? quotes@globalpartsupply.com

Shipping: $33.85 per item. The same price to anywhere in the 50 states.

Buying several? Shipping is charged per item — call (312) 564-5212 or request a combined quote.

Ships same or next business day · UPS Ground or comparable carrier, typically 1–5 business days.

Shipping details

Specifications

Product Type:
Gearmotor
Voltage:
115/208-230V
Phase:
Single Phase
Horsepower:
0.33 HP
RPM:
288 RPM
Frame Size:
48Y Frame
Mounting Type:
Special
Motor Type:
Capacitor Start
Power (kW):
0.25 kW
Service Factor:
1.15
KVA Code:
L
Output Torque:
70 lb-in
Duty:
Continuous
Ambient Temperature:
40°C
Bearing Sizes:
shaft end 6203, opposite end 6203
Shaft Type:
Parallel
Overall Length:
13.67"
Frame Length:
5 3/4"
Material:
Rolled Steel
Certifications:
UL Recognized, CSA
Country of Origin:
USA
UPC:
691720006351
Leeson 107007.00 is a parallel shaft gearmotor rated 0.33 HP at 288 RPM, 115/208-230V single-phase 60 Hz. It has a 48Y frame and a totally enclosed fan cooled enclosure. Reversible rotation; full-load current 6.2/3.1 A; Class B insulation; service factor 1.15; shaft diameter 3/4".
!
