Leeson 103794.00 Instant Reversing Motor 1/3 HP 115V

Leeson

$437.95

In Stock

Write a Review
SKU:
103794.00
Adding to cart… The item has been added

30-day returns on most unused, uninstalled parts Secure checkout with cards, PayPal or Google Pay Questions? quotes@globalpartsupply.com

Shipping: $31.32 per item. The same price to anywhere in the 50 states.

Buying several? Shipping is charged per item — request a combined quote.

Ships same or next business day · UPS Ground or comparable carrier, typically 1–5 business days.

Specifications

Product Type:
Instant Reversing Motor
Subcategory:
Single-Phase AC Motor
Application:
Commercial
Installation Type:
OEM Replacement
Voltage:
115V
Voltage Class:
Line Voltage
Phase:
Single Phase
Amperage:
4.2 A
Horsepower:
1/3 HP
RPM:
1625 RPM
Speeds:
1
Frame Size:
56 Frame
Mounting Type:
Resilient Base
Fuel Type:
Electric
Material:
Rolled Steel
Motor Type:
PSC
Power (kW):
0.25 kW
Service Factor:
1.0
KVA Code:
A
NEMA Design:
N
Power Factor:
96%
Duty:
60 Minute
Ambient Temperature:
40°C
Starting Method:
Across The Line
Bearings:
Ball / Ball
Bearing Sizes:
shaft end 6203, opposite end 6203
Shaft Type:
Nema 56
Overall Length:
10 13/16"
Frame Length:
6"
Mounting Orientation:
Horizontal
Assembly Position:
F1 Only
IP Rating:
IP12
UPC:
691720089293
Lifecycle Status:
Active
Leeson 1/3 HP single-phase instant reversing motor, 1625 RPM, 115V, NEMA 56 frame with ODP enclosure. Features permanent split capacitor design, ball bearings, and resilient base mounting for quick reversing applications like gates and doors. Manual overload protection and Class B insulation.
