Leeson 102016.00 Motor 1/3 HP 115/230V 3450 RPM

Leeson

$290.95

In Stock

Write a Review
SKU:
102016.00
Adding to cart… The item has been added

30-day returns on most unused, uninstalled parts Secure checkout with cards, PayPal or Google Pay Questions? quotes@globalpartsupply.com

Shipping: $26.70 per item. The same price to anywhere in the 50 states.

Buying several? Shipping is charged per item — request a combined quote.

Ships same or next business day · UPS Ground or comparable carrier, typically 1–5 business days.

Specifications

Product Type:
Single-Phase Motor
Subcategory:
General Purpose / Blower
Application:
Residential/Commercial
System Type:
Furnace, Air Handler, Heat Pump
Installation Type:
OEM Replacement
Voltage:
115/230V
Voltage Class:
Line Voltage
Phase:
Single Phase
Horsepower:
1/3 HP
RPM:
3450 RPM
Speeds:
1
Fuel Type:
Electric
Mounting Type:
Rigid Base
Frame Size:
48 Frame
Motor Type:
Capacitor Start
Power (kW):
0.25 kW
Service Factor:
1.15
KVA Code:
M
NEMA Design:
N
Power Factor:
59%
Duty:
Continuous
Ambient Temperature:
40°C
Starting Method:
Across The Line
Bearings:
Ball / Ball
Bearing Sizes:
shaft end 6203, opposite end 6203
Shaft Type:
Nema 48
Overall Length:
9 1/16"
Frame Length:
4 3/4"
Mounting Orientation:
Horizontal
Assembly Position:
F1 Only
IP Rating:
IP43
Material:
Rolled Steel
Certifications:
UL Recognized, CSA
Country of Origin:
Mexico
UPC:
691720006146
Lifecycle Status:
Active
Leeson 1/3 HP single-phase TEFC motor rated for 115/230V operation at 3450 RPM. Fully enclosed fan-cooled design suitable for HVAC blower applications, pump drives, and general industrial use. OEM replacement and universal fit applications.
