Leeson 100700.00 1/3 HP Motor 115/230V 1800 RPM TENV

Leeson

$277.95

In Stock

Write a Review
SKU:
100700.00
Adding to cart… The item has been added

30-day returns on most unused, uninstalled parts Secure checkout with cards, PayPal or Google Pay Questions? quotes@globalpartsupply.com

Shipping: $31.10 per item. The same price to anywhere in the 50 states.

Buying several? Shipping is charged per item — request a combined quote.

Ships same or next business day · UPS Ground or comparable carrier, typically 1–5 business days.

Specifications

Product Type:
Single-Phase Motor
Subcategory:
Fractional Horsepower
Application:
Residential/Commercial
System Type:
Fan, Blower
Installation Type:
OEM Replacement
Voltage:
115/230V
Voltage Class:
Line Voltage
Phase:
Single Phase
Amperage:
3.2/1.6 A
Horsepower:
1/3 HP
RPM:
1625 RPM
Speeds:
1
Frame Size:
48Y Frame
Mounting Type:
Rigid Base
Fuel Type:
Electric
Motor Type:
PSC
Power (kW):
0.25 kW
Service Factor:
1.0
KVA Code:
D
NEMA Design:
N
Power Factor:
94%
Duty:
Continuous
Ambient Temperature:
40°C
Starting Method:
Across The Line
Bearings:
Ball / Ball
Bearing Sizes:
shaft end 6203, opposite end 6203
Shaft Type:
Nema 48
Overall Length:
10.65"
Frame Length:
5 1/2"
Mounting Orientation:
Horizontal
Assembly Position:
F1 Only
IP Rating:
IP43
Material:
Rolled Steel
Certifications:
UL Recognized, CSA
Country of Origin:
Mexico
UPC:
691720005002
Lifecycle Status:
Active
Leeson 1/3 HP single-phase motor rated 115/230V, 60 Hz, 1800 RPM. TENV enclosure with rigid base, 48Y frame, and 1/2" flat shaft. PSC (Permanent Split Capacitor) design with auto overload protection and 1.0 service factor. Ideal for farm duty fan applications.
