Hydrolevel CG450-1560 Low Water Cut-Off 120V Steam Boiler

Hydrolevel CG450-1560 Low Water Cut-Off 120V Steam Boiler

Hydrolevel

$222.95

In Stock — 10+ available

Write a Review
SKU:
CG450-1560
Adding to cart… The item has been added

30-day returns on most unused, uninstalled parts Secure checkout with cards, PayPal or Google Pay Questions? quotes@globalpartsupply.com

Flat-rate shipping. The same price to anywhere in the 50 states.

Ships same or next business day · UPS Ground or comparable carrier, typically 1–5 business days.

Shipping details

Specifications

Product Type:
Low Water Cut-Off Control
Subcategory:
Steam Boiler Protection
Application:
Residential/Commercial
System Type:
Boiler
Installation Type:
OEM Replacement
Voltage:
120V
Voltage Class:
Line Voltage
Phase:
Single Phase
Mounting Type:
Direct Boiler Mount
Pressure Rating:
15 PSI
Inlet Size:
3/4" NPT
Connection Type:
NPT
Control Type:
Non-Programmable
Switch Action:
SPDT
The Hydrolevel CG450-1560 is a 120V low water cut-off control for residential and commercial steam boilers up to 15 PSI. It features Intermittent Level Test (ILT) technology that monitors water level every 15 minutes for 60 seconds, preventing false shutdowns caused by foaming. The control includes a 15-second burner shut-down delay and 30-second restart delay with automatic reset, solid-state circuitry, and direct boiler mounting via 3/4" NPT connection.
!
