Genteq 3739 is a condenser fan motor rated 3/4 HP at 1075 RPM, 460V. It has a totally enclosed air over enclosure and extended studs mounting. Thermally protected.
Genteq 3739 Condenser Fan Motor
Regal Rexnord - Genteq
$405.95
In Stock — 10+ available
- Replaced by
- FEH1076SF
Write a Review
Write a Review
Regal Rexnord - Genteq
Genteq 3739 Condenser Fan Motor
- SKU:
- GPS-100144
- Manufacturer Part #
- 3739
Specifications
- Product Type:
- Condenser Fan Motor
- Voltage:
- 460V
- Phase:
- Single Phase
- Horsepower:
- 3/4 HP
- RPM:
- 1075 RPM
- Speeds:
- 1
- Frame Size:
- 48 Frame
- Mounting Type:
- Extended Studs
- Motor Type:
- PSC
- Power (kW):
- 0.56 kW
- Service Factor:
- 1.0
- Duty:
- Continuous Air Over
- Ambient Temperature:
- 40°C
- Run Capacitor:
- 10 MFD 370V
- Bearings:
- Ball / Ball
- Shaft Type:
- Double Flat
- Overall Length:
- 13 5/16"
- Frame Length:
- 5.57"
- Mounting Orientation:
- Horizontal
- Material:
- Rolled Steel
- Certifications:
- UL Recognized, CSA, A2L Compliant
- Country of Origin:
- Mexico
- UPC:
- 815585021124
- Lifecycle Status:
- Discontinued by manufacturer
