1/4 HP permanent split capacitor (PSC) condenser fan motor rated 230V 60Hz 1075 RPM. Reversible rotation, totally enclosed air-over enclosure, suitable for residential air conditioner condenser units. Includes 1/2" x 6-1/2" shaft, belly band or base mount options, and ball bearings. Requires 5 MFD 370V capacitor (sold separately).
Fasco D7909 Condenser Fan Motor 1/4 HP 208/230V
Regal Rexnord - Fasco
$110.95
In Stock — 10+ available
Write a Review
Write a Review
Regal Rexnord - Fasco
Fasco D7909 Condenser Fan Motor 1/4 HP 208/230V
- SKU:
- D7909
Specifications
- Product Type:
- Condenser Fan Motor
- Subcategory:
- PSC Blower Motor
- Application:
- Residential
- System Type:
- Air Conditioner, Split System
- Installation Type:
- OEM Replacement
- Voltage:
- 208-230V
- Voltage Class:
- Line Voltage
- Phase:
- Single Phase
- Amperage:
- 1.8A
- Horsepower:
- 1/4 HP
- RPM:
- 1075 RPM
- Speeds:
- 1
- MFD:
- 5 MFD 370V
- Mounting Type:
- Belly Band, Base Mount
- Fuel Type:
- Electric
- Frame Size:
- 48 Frame
- Material:
- Rolled Steel
- Motor Type:
- PSC
- Power (kW):
- 0.19 kW
- Service Factor:
- 1.0
- Duty:
- Continuous
- Ambient Temperature:
- 60°C
- Starting Method:
- Across The Line
- Run Capacitor:
- 5 MFD 370V
- Bearings:
- Ball / Ball
- Shaft Type:
- Double Flat
- Frame Length:
- 3.98"
- Country of Origin:
- Thailand
- UPC:
- 818508020280
- Lifecycle Status:
- Active
