FASCO 1/30 HP general-purpose fan and blower motor, 115V single-phase 60Hz, 1500 RPM. Features 3.3" diameter open air-over enclosure with thermally protected shaded pole design and sleeve bearing. 5/16" shaft with flat, 12" leads. UL Recognized and CSA certified.
Fasco D514 Fan Motor 1/30 HP 115V 1500 RPM
Regal Rexnord - Fasco
$68.95
In Stock — 10+ available
Write a Review
Write a Review
Regal Rexnord - Fasco
Fasco D514 Fan Motor 1/30 HP 115V 1500 RPM
- SKU:
- D514
Specifications
- Product Type:
- Fan and Blower Motor
- Subcategory:
- General Purpose AC Motor
- Application:
- Residential/Commercial
- System Type:
- HVAC/R Systems, Fan Coil Units, Air Handlers
- Installation Type:
- OEM Replacement
- Voltage:
- 115V
- Phase:
- Single Phase
- Amperage:
- 1.30A
- Horsepower:
- 1/30 HP
- RPM:
- 1500 RPM
- Speeds:
- 1
- Frame Size:
- 3.3 Frame
- Mounting Type:
- OAO (Open and Open)
- Fuel Type:
- Electric
- Voltage Class:
- Line Voltage
- Material:
- Rolled Steel
- Motor Type:
- Shaded Pole
- Power (kW):
- 0.02 kW
- Service Factor:
- 1.0
- Duty:
- Air Over
- Ambient Temperature:
- 40°C
- Starting Method:
- Across The Line
- Bearings:
- Sleeve / Sleeve
- Shaft Type:
- Flat
- Overall Length:
- 5.3"
- Frame Length:
- 2 1/2"
- Country of Origin:
- Mexico
- UPC:
- 818508020723
- Lifecycle Status:
- Active
