Century XEL2014 Definite Purpose Motor 1/6 HP 115V

Regal Rexnord - Century Motors

$160.95

In Stock — 10+ available

Write a Review
SKU:
XEL2014
Adding to cart… The item has been added

30-day returns on most unused, uninstalled parts Secure checkout with cards, PayPal or Google Pay Questions? quotes@globalpartsupply.com

Shipping: $25.05 per item. The same price to anywhere in the 50 states.

Buying several? Shipping is charged per item — email quotes@globalpartsupply.com for a combined quote.

Ships same or next business day · UPS Ground or comparable carrier, typically 1–5 business days.

Specifications

Product Type:
Definite Purpose Motor
Subcategory:
Oil Burner Motor
Application:
Residential/Commercial
System Type:
Oil Burner, Furnace
Installation Type:
OEM Replacement
Voltage:
115V
Voltage Class:
Line Voltage
Phase:
Single Phase
Amperage:
3.2A
Horsepower:
1/6 HP
RPM:
1725 RPM
Speeds:
1
Frame Size:
48N Frame
Mounting Type:
N
Motor Type:
Split Phase
Power (kW):
0.13 kW
Service Factor:
1.0
Duty:
Continuous
Ambient Temperature:
40°C
Starting Method:
Across The Line
Bearings:
Sleeve / Sleeve
Shaft Type:
Flat
Overall Length:
7.66"
Frame Length:
3 11/16"
Material:
Rolled Steel
Country of Origin:
Mexico
UPC:
786674033901
Lifecycle Status:
Active
Century 1/6 HP definite purpose motor for HVAC/R applications. Single-phase, 115V, 1725 RPM, 48N frame, totally enclosed non-ventilated (TENV) enclosure with manual thermal protection. Sleeve bearing design rated for continuous duty. Suitable for oil burner and similar applications.
