Century 2.5 HP single-phase pool pump motor with 230V supply, 3450 RPM, and 48Y square flange frame. Features sealed ball bearings, capacitor start, open drip-proof enclosure, and 303 stainless steel shaft. UL 1081 design rated for continuous duty with 1.0 service factor. Ideal replacement for in-ground pool pump applications.
Century USQ1252 Pool Pump Motor 2.5 HP 230V 3450 RPM
Regal Rexnord - Century Motors
$522.95
In Stock — 10+ available
- SKU:
- USQ1252
Specifications
- Product Type:
- Pool Pump Motor
- Subcategory:
- Single-Phase AC Motor
- Application:
- Residential
- System Type:
- Pool Pump
- Installation Type:
- OEM Replacement
- Voltage:
- 230V
- Voltage Class:
- Line Voltage
- Phase:
- Single Phase
- Amperage:
- 11.2A
- Horsepower:
- 2.5 HP
- RPM:
- 3450 RPM
- Speeds:
- 1
- Frame Size:
- 48Y Frame
- Mounting Type:
- Square Flange
- Temperature Range:
- 50°C Ambient
- Fuel Type:
- Electric
- Material:
- 303 Stainless Steel (shaft)
- Motor Type:
- Capacitor Start / Capacitor Run
- Power (kW):
- 1.9 kW
- Service Factor:
- 1.0
- Duty:
- Continuous
- Ambient Temperature:
- 50°C
- Starting Method:
- Across The Line
- Bearings:
- Ball / Ball
- Shaft Type:
- 1/2 Thread
- Overall Length:
- 14.57"
- Frame Length:
- 10 11/16"
- Mounting Orientation:
- Horizontal
- Country of Origin:
- Mexico
- UPC:
- 786674033277
- Lifecycle Status:
- Discontinued by manufacturer
