Century USQ1252 Pool Pump Motor 2.5 HP 230V 3450 RPM

Regal Rexnord - Century Motors

$522.95

In Stock — 10+ available

Write a Review
SKU:
USQ1252
Adding to cart… The item has been added

30-day returns on most unused, uninstalled parts Secure checkout with cards, PayPal or Google Pay Questions? quotes@globalpartsupply.com

Shipping: $35.50 per item. The same price to anywhere in the 50 states.

Buying several? Shipping is charged per item — request a combined quote.

Ships same or next business day · UPS Ground or comparable carrier, typically 1–5 business days.

Specifications

Product Type:
Pool Pump Motor
Subcategory:
Single-Phase AC Motor
Application:
Residential
System Type:
Pool Pump
Installation Type:
OEM Replacement
Voltage:
230V
Voltage Class:
Line Voltage
Phase:
Single Phase
Amperage:
11.2A
Horsepower:
2.5 HP
RPM:
3450 RPM
Speeds:
1
Frame Size:
48Y Frame
Mounting Type:
Square Flange
Temperature Range:
50°C Ambient
Fuel Type:
Electric
Material:
303 Stainless Steel (shaft)
Motor Type:
Capacitor Start / Capacitor Run
Power (kW):
1.9 kW
Service Factor:
1.0
Duty:
Continuous
Ambient Temperature:
50°C
Starting Method:
Across The Line
Bearings:
Ball / Ball
Shaft Type:
1/2 Thread
Overall Length:
14.57"
Frame Length:
10 11/16"
Mounting Orientation:
Horizontal
Country of Origin:
Mexico
UPC:
786674033277
Lifecycle Status:
Discontinued by manufacturer
Century 2.5 HP single-phase pool pump motor with 230V supply, 3450 RPM, and 48Y square flange frame. Features sealed ball bearings, capacitor start, open drip-proof enclosure, and 303 stainless steel shaft. UL 1081 design rated for continuous duty with 1.0 service factor. Ideal replacement for in-ground pool pump applications.
