Century OL2052D Definite Purpose Motor 1/2 HP 115/230V

Specifications

Product Type:

Definite Purpose Motor

Subcategory:

Oil Burner Motor

Application:

Residential/Commercial

System Type:

Oil Burner, HVAC

Installation Type:

OEM Replacement

Voltage:

115/230V

Voltage Class:

Line Voltage

Phase:

Single Phase

Amperage:

6.2/3.1 A

Horsepower:

1/2 HP

RPM:

3450 RPM

Speeds:

1

Frame Size:

48N Frame

Mounting Type:

N

Motor Type:

Split Phase

Power (kW):

0.37 kW

Service Factor:

1.0

Duty:

Continuous

Ambient Temperature:

40°C

Starting Method:

Across The Line

Bearings:

Sleeve / Sleeve

Shaft Type:

Flat

Overall Length:

8.72"

Frame Length:

4 15/16"

Material:

Rolled Steel

Certifications:

CSA

Country of Origin:

Mexico

UPC:

786674027849

Lifecycle Status:

Discontinued by manufacturer
