1 HP condenser fan motor, 200-230/460V single-phase, 1075 RPM, 48 frame, open enclosure with reversible rotation. Permanent split capacitor design with ball bearings and round belly band mounting. Requires 25 MFD 370V capacitor.
Century Motors FC1106F Condenser Fan Motor 1HP 200-230/460V
Regal Rexnord - Century Motors
$476.95
In Stock — 10+ available
Write a Review
Write a Review
Regal Rexnord - Century Motors
Century Motors FC1106F Condenser Fan Motor 1HP 200-230/460V
- SKU:
- FC1106F
Specifications
- Product Type:
- Condenser Fan Motor
- Subcategory:
- Single-Phase AC Motor
- Application:
- Residential/Commercial
- System Type:
- Split System, Package Unit, Air Handler
- Installation Type:
- OEM Replacement
- Voltage:
- 200-230/460V
- Phase:
- Single Phase
- Amperage:
- 6.4/3.2 A
- Horsepower:
- 1 HP
- RPM:
- 1075 RPM
- Speeds:
- 1
- MFD:
- 25 MFD 370V
- Frame Size:
- 48Y Frame
- Mounting Type:
- Round Belly Band
- Material:
- Rolled Steel
- Motor Type:
- PSC
- Power (kW):
- 0.75 kW
- Service Factor:
- 1.0
- Duty:
- Air Over
- Ambient Temperature:
- 70°C
- Starting Method:
- Across The Line
- Run Capacitor:
- 25 MFD 370V
- Bearings:
- Ball / Ball
- Shaft Type:
- Keyed
- Overall Length:
- 15 7/16"
- Frame Length:
- 9"
- Mounting Orientation:
- Vertical Shaft Up
- Country of Origin:
- Mexico
- UPC:
- 786674020383
- Lifecycle Status:
- Active
