Century Motors 9722 Condenser Fan Motor 1/8-1/12 HP 208-230V

Regal Rexnord - Century Motors

$125.95

In Stock — 10+ available

Write a Review
SKU:
9722
Adding to cart… The item has been added

30-day returns on most unused, uninstalled parts Secure checkout with cards, PayPal or Google Pay Questions? quotes@globalpartsupply.com

Shipping: $23.45 per item. The same price to anywhere in the 50 states.

Buying several? Shipping is charged per item — request a combined quote.

Ships same or next business day · UPS Ground or comparable carrier, typically 1–5 business days.

Specifications

Product Type:
Condenser Fan Motor
Subcategory:
Multi-Horsepower PSC Motor
Application:
Residential/Commercial
System Type:
Split System, Package Unit, Air Conditioning
Installation Type:
OEM Replacement
Voltage:
208-230V
Voltage Class:
Line Voltage
Phase:
Single Phase
Amperage:
0.9 A
Horsepower:
1/8-1/10-1/12 HP
RPM:
1075 RPM
Speeds:
1
MFD:
5 MFD 440V
Frame Size:
42 Frame
Mounting Type:
Multi-Mounting System (4.33", 4.42", 4.62" Bolt Circle)
Fuel Type:
Electric
Material:
Rolled Steel
A2L Refrigerant:
Yes
Motor Type:
PSC
Power (kW):
0.1 kW
Service Factor:
1.0
Duty:
Air Over
Ambient Temperature:
70°C
Starting Method:
Across The Line
Run Capacitor:
5 MFD 440V
Bearings:
Ball / Ball
Shaft Type:
Flat
Overall Length:
7 1/2"
Frame Length:
4.27"
Mounting Orientation:
Any
Assembly Position:
Any
Country of Origin:
India
UPC:
786674009838
Lifecycle Status:
Active
Century Motors 9722 is a multi-horsepower (1/8, 1/10, 1/12 HP) condenser fan motor for residential and light commercial air conditioning systems. Operates at 208-230V single-phase, 60 Hz, 1075 RPM with a 42-frame TEAO enclosure. Features Permanent Split Capacitor (PSC) design, reversible rotation, and MultiFit mounting system compatible with multiple bolt circles. Requires 5 MFD 440V capacitor (sold separately).
