Century 3 HP single-phase aeration fan motor rated 230V, 3450 RPM with P145T frame and TEAO enclosure. Designed for belt-driven or direct-drive fan applications in agricultural and general-purpose settings.
Century K116 Aeration Fan Motor 3 HP 230V 3450 RPM
Regal Rexnord - Century Motors
$429.95
In Stock
- SKU:
- K116
Specifications
- Product Type:
- AC Motor
- Subcategory:
- Aeration Fan Motor
- Application:
- Residential/Commercial
- System Type:
- Aeration Fan, Belt Drive Fan, Direct Drive Fan
- Installation Type:
- OEM Replacement
- Voltage:
- 230V
- Voltage Class:
- Line Voltage
- Phase:
- Single Phase
- Amperage:
- 15.4A
- Horsepower:
- 3 HP
- RPM:
- 3450 RPM
- Speeds:
- 1
- Frame Size:
- P145T Frame
- Mounting Type:
- Belt Drive
- Fuel Type:
- Electric
- Motor Type:
- PSC
- Power (kW):
- 2.2 kW
- Service Factor:
- 1.0
- Duty:
- Continuous
- Ambient Temperature:
- 40°C
- Starting Method:
- Across The Line
- Bearings:
- Ball / Ball
- Shaft Type:
- Keyed
- Overall Length:
- 13 13/16"
- Frame Length:
- 8"
- Material:
- Rolled Steel
- Country of Origin:
- Mexico
- UPC:
- 786674025685
- Lifecycle Status:
- Active
