Century K100V1 General Purpose Motor 1 HP 115/208-230V

Regal Rexnord - Century Motors

$109.95
Write a Review
SKU:
K100V1

Discontinued

This part is no longer made, and none of our suppliers has stock. Send us the nameplate details and we’ll look for a replacement.

Ask about a replacement

We reply within one business day — quotes@globalpartsupply.com

Specifications

Product Type:
General Purpose Motor
Application:
Residential/Commercial
Installation Type:
OEM Replacement
Voltage:
115/208-230V
Voltage Class:
Line Voltage
Phase:
Single Phase
Horsepower:
1 HP
RPM:
1745 RPM
Speeds:
1
Mounting Type:
Rigid Base
Frame Size:
143T Frame
Motor Type:
Capacitor Start
Power (kW):
0.75 kW
Service Factor:
1.15
Duty:
Continuous
Ambient Temperature:
40°C
Starting Method:
Across The Line
Bearings:
Ball / Ball
Shaft Type:
Keyed
Overall Length:
13.73"
Frame Length:
6 3/4"
Material:
Rolled Steel
Certifications:
UL Recognized, CSA
Country of Origin:
Mexico
UPC:
786674071606
Lifecycle Status:
Discontinued by manufacturer
Century 1 HP general purpose motor with TEFC enclosure, rated for 115/208-230V single-phase operation at 1745 RPM. Suitable for a wide range of HVAC and industrial applications requiring reliable, durable motor performance.
