Century 5 HP three-phase general purpose motor rated 460/208-230V, 3450 RPM, Y56HZ frame. Premium efficiency (86.5%) with heavy-duty rolled steel construction, sealed bearings, and drip-proof enclosure.
Century H847 General Purpose Motor 5 HP 3-Phase 460/208-230V
Regal Rexnord - Century Motors
$621.95
In Stock — 10+ available
- SKU:
- H847
Specifications
- Product Type:
- General-Purpose Motor
- Subcategory:
- Three-Phase AC Motor
- Application:
- Commercial/Industrial
- System Type:
- HVAC, Industrial Equipment, Pump Drives, Fan Duty
- Installation Type:
- OEM Replacement
- Voltage:
- 460/208-230V
- Voltage Class:
- Line Voltage
- Phase:
- Three Phase
- Amperage:
- 6.6/13.4-13.2 A
- Horsepower:
- 5 HP
- RPM:
- 3450 RPM
- Speeds:
- 1
- Frame Size:
- Y56HZ Frame
- Fuel Type:
- Electric
- Material:
- Rolled Steel
- Mounting Type:
- Rigid Base
- Motor Type:
- Three Phase
- Power (kW):
- 3.7 kW
- Service Factor:
- 1.15
- Duty:
- Continuous
- Ambient Temperature:
- 40°C
- Starting Method:
- Across The Line
- Bearings:
- Ball / Ball
- Shaft Type:
- Keyed
- Overall Length:
- 15 1/16"
- Frame Length:
- 9 1/4"
- Country of Origin:
- Mexico
- UPC:
- 786674024466
- Lifecycle Status:
- Active
