Century 2 HP three-phase general purpose motor with TEFC enclosure, rated for 200-230/460V operation at 1725 RPM. Suitable for a wide range of HVAC and industrial applications including compressors, pumps, and fans. Built to OEM specifications for reliable performance.
Century H703LES General Purpose Motor 2 HP 3-Phase 1725 RPM
Regal Rexnord - Century Motors
$612.95
In Stock
- Replaced by
- FX02BK004
- SKU:
- H703LES
Specifications
- Product Type:
- General Purpose Motor
- Application:
- Residential/Commercial
- System Type:
- Compressor, Pump, Fan, Air Handler
- Installation Type:
- OEM Replacement
- Voltage:
- 200-230/460V
- Voltage Class:
- Line Voltage
- Phase:
- Three Phase
- Horsepower:
- 2 HP
- RPM:
- 1725 RPM
- Speeds:
- 1
- Fuel Type:
- Electric
- Mounting Type:
- Round
- Frame Size:
- 56C Frame
- Motor Type:
- Three Phase
- Power (kW):
- 1.5 kW
- Service Factor:
- 1.15
- Duty:
- Continuous
- Ambient Temperature:
- 40°C
- Starting Method:
- Across The Line
- Bearings:
- Ball / Ball
- Shaft Type:
- Nema 56
- Overall Length:
- 15.15"
- Frame Length:
- 9 3/4"
- Material:
- Rolled Steel
- Certifications:
- UL Recognized, CSA, CE
- Country of Origin:
- Mexico
- UPC:
- 786674074133
- Lifecycle Status:
- Discontinued by manufacturer
