Century FDL6002A is a multi-horsepower (3/4–1/5 HP) permanent split capacitor (PSC) fan and blower motor rated for 115V single-phase operation at 1075 RPM. Features a 48 NEMA frame, open air-over enclosure, reversible rotation, and 4-speed capability for flexible HVAC applications in residential and light commercial furnaces, air handlers, and rooftop units. Includes thermal overload protection and ball bearings for reliable long-term service.
Century FDL6002A Fan Blower Motor 3/4 HP 115V 1075 RPM
Regal Rexnord - Century Motors
$167.95
In Stock — 10+ available
- SKU:
- FDL6002A
Specifications
- Product Type:
- Fan and Blower Motor
- Subcategory:
- Permanent Split Capacitor (PSC) Multi-Speed
- Application:
- Residential/Commercial
- System Type:
- Furnace, Air Handler, Rooftop Unit
- Installation Type:
- OEM Replacement
- Voltage:
- 115V
- Voltage Class:
- Line Voltage
- Phase:
- Single Phase
- Amperage:
- 9.1A
- Horsepower:
- 3/4-1/5 HP
- RPM:
- 1075 RPM
- Speeds:
- 4
- MFD:
- 10 MFD 370V
- Frame Size:
- 48 Frame
- Mounting Type:
- Belly Band, Stud Mount
- Temperature Range:
- -40°C to 40°C
- Fuel Type:
- Electric
- Material:
- Rolled Steel Shell
- Motor Type:
- PSC
- Power (kW):
- 0.56 kW
- Service Factor:
- 1.0
- Duty:
- Air Over
- Ambient Temperature:
- 40°C
- Starting Method:
- Across The Line
- Run Capacitor:
- 5 MFD 370V
- Bearings:
- Ball / Ball
- Shaft Type:
- Flat
- Overall Length:
- 10.3"
- Frame Length:
- 4 1/4"
- Mounting Orientation:
- Horizontal
- Certifications:
- UL Recognized, CSA, A2L Certified
- Country of Origin:
- India
- UPC:
- 786674054777
- Lifecycle Status:
- Active
