Century 1/4 HP open-frame fan and blower motor rated for 115V single-phase operation at 1075 RPM. Designed for direct-drive applications in residential and light commercial HVAC systems. Air-over enclosure provides cooling for continuous-duty operation.
Century DL001 Fan Blower Motor 1/4 HP 115V 1075 RPM
Regal Rexnord - Century Motors
$115.95
In Stock
- SKU:
- DL001
Specifications
- Product Type:
- Fan Blower Motor
- Subcategory:
- Direct-Drive Blower
- Application:
- Residential/Commercial
- System Type:
- Furnace, Air Handler, Package Unit
- Installation Type:
- OEM Replacement
- Voltage:
- 115V
- Voltage Class:
- Line Voltage
- Phase:
- Single Phase
- Horsepower:
- 1/4 HP
- RPM:
- 1075 RPM
- Speeds:
- 2
- Mounting Type:
- Direct Drive
- Fuel Type:
- Electric
- Frame Size:
- 48Y Frame
- Motor Type:
- PSC
- Power (kW):
- 0.19 kW
- Service Factor:
- 1.0
- Duty:
- Air Over
- Ambient Temperature:
- 40°C
- Starting Method:
- Across The Line
- Run Capacitor:
- 5 MFD 370V
- Bearings:
- Sleeve / Sleeve
- Shaft Type:
- Flat
- Overall Length:
- 9.11"
- Frame Length:
- 3 1/2"
- Mounting Orientation:
- Horizontal
- Material:
- Rolled Steel
- Certifications:
- UL Recognized, CSA, A2L Compliant
- UPC:
- 786674018502
- Lifecycle Status:
- Discontinued by manufacturer
