Century 0.25 HP fan and blower motor rated for 115V single-phase operation at 1725 RPM. TEAO (Totally Enclosed Air Over) enclosure suitable for residential and light commercial HVAC applications. Direct-drive design for furnace blowers, air handlers, and similar equipment.
Century ARB2024M Fan Blower Motor 0.25 HP 115V 1725 RPM
Regal Rexnord - Century Motors
$329.95
In Stock — 10+ available
- SKU:
- ARB2024M
Specifications
- Product Type:
- Fan Blower Motor
- Subcategory:
- Blower Motor
- Application:
- Residential/Commercial
- System Type:
- Furnace, Air Handler, Package Unit
- Installation Type:
- OEM Replacement
- Voltage:
- 115V
- Voltage Class:
- Line Voltage
- Phase:
- Single Phase
- Horsepower:
- 1/4 HP
- RPM:
- 1725 RPM
- Speeds:
- 1
- Mounting Type:
- Cushion Base
- Frame Size:
- 56Z Frame
- Motor Type:
- Split Phase
- Power (kW):
- 0.19 kW
- Service Factor:
- 1.0
- Duty:
- Continuous
- Ambient Temperature:
- 40°C
- Starting Method:
- Across The Line
- Bearings:
- Sleeve / Sleeve
- Shaft Type:
- Flat
- Overall Length:
- 10.07"
- Frame Length:
- 4 1/8"
- Material:
- Rolled Steel
- Certifications:
- UL Recognized, CSA
- Country of Origin:
- Mexico
- UPC:
- 786674011565
- Lifecycle Status:
- Active
