Century 9432A Fan Coil Motor 1/4 HP 277V 1075 RPM

Regal Rexnord - Century Motors

$317.95

In Stock — 10+ available

Write a Review
SKU:
9432A
Adding to cart… The item has been added

30-day returns on most unused, uninstalled parts Secure checkout with cards, PayPal or Google Pay Questions? quotes@globalpartsupply.com

Shipping: $24.50 per item. The same price to anywhere in the 50 states.

Buying several? Shipping is charged per item — email quotes@globalpartsupply.com for a combined quote.

Ships same or next business day · UPS Ground or comparable carrier, typically 1–5 business days.

Specifications

Product Type:
Fan Coil Motor
Subcategory:
AC Motor
Application:
Residential/Commercial
System Type:
Fan Coil, Air Handler, Air Conditioner
Installation Type:
OEM Replacement
Voltage:
277V
Voltage Class:
Line Voltage
Phase:
Single Phase
Amperage:
1.2, 0.75, 0.55 A
Horsepower:
1/4, 1/6, 1/8 HP
RPM:
1075 RPM
Speeds:
3
Frame Size:
48Y Frame
Mounting Type:
Lug
Fuel Type:
Electric
Material:
Rolled Steel
Motor Type:
PSC
Power (kW):
0.19 kW
Service Factor:
1.0
Duty:
Air Over
Ambient Temperature:
60°C
Starting Method:
Across The Line
Run Capacitor:
5 MFD 370V
Bearings:
Ball / Ball
Shaft Type:
Flat
Overall Length:
9.74"
Frame Length:
3 5/8"
Mounting Orientation:
Horizontal
Country of Origin:
India
UPC:
786674011275
Lifecycle Status:
Active
Three-speed permanent split capacitor motor for fan coil and air conditioner applications. 1/4, 1/6, or 1/8 HP at 277V single-phase 60 Hz, 1075 RPM. 48Y frame, open enclosure, reversible rotation.
