Antunes JD-2 differential pressure switch with red spring, adjustable 0.1" to 24" W.C. Snap-action SPDT switch rated 10A @ 125VAC or 5A @ 250VAC. Compact die-cast aluminum housing with visible ON-OFF indicator and dual-scale adjustment (inches and millimeters). UL, FM, and CSA listed for combustion safeguard and air proving applications.
Antunes 801111303 JD-2 Pressure Switch 0.1-24" W.C.
A.J. Antunes
$116.95
In Stock — 10+ available
(No reviews yet)
Write a Review
Write a Review
A.J. Antunes
Antunes 801111303 JD-2 Pressure Switch 0.1-24" W.C.
- SKU:
- 801111303
- Product Type:
- Differential Pressure Switch
- Subcategory:
- Air Proving Switch
- Application:
- Commercial
- System Type:
- Furnace, Boiler, Rooftop Unit
- Installation Type:
- OEM Replacement
- Voltage:
- 125V
- Voltage Class:
- Line Voltage
- Phase:
- Single Phase
- Amperage:
- 10A
- Horsepower:
- 1/8 HP
- Mounting Type:
- Stud Mount
- Temperature Range:
- -20°F to 140°F
- Setpoint Range:
- 0.1" to 24" W.C.
- Pressure Rating:
- 35" W.C. max operating
- Inlet Size:
- 1/8" NPT
- Connection Type:
- NPT
- Connection / Joint:
- NPT
- Material:
- Die-Cast Aluminum
- Control Type:
- Non-Programmable
- Switch Action:
- SPDT
